Copy of LEDSON Sarox9+ Gen2 LED Spot Light with beacon strobe

Sarox9+ Gen2 Strobe has 11,500 effective lumens and a solid 747-meter range in powerboost mode (360 meters in E-approved mode), providing a balanced combination of width and range. In addition, this variant of the Sarox9+ also has strobe lights with five different patterns and the ability to synchronize the lights with each other!

Strobe patterns
Single flash (ECE R65 approved), double flash, triple flash, quadruple flash, continuous hyper flash.

Stone chip protection and snow filter
For vehicles where the auxiliary lights are exposed to harsh conditions, we recommend adding stone chip protection to minimise the risk of stone chips and scratches and thus extend the service life. Snow filters are also available as Accessories. See related products.

Synchronizable and with alternating flash pattern
Sarox9+ Gen2 Strobe can be synchronized with each other, which means that all of the lights use the same flash pattern and strobe synchronized. You can synchronize an infinite number of lights, i.e. there are no restrictions on the number of lights you use.

Pulse-Controlled powerboost - It doesn't get smoother than this
Sarox9+ Gen2 Strobe comes equipped with powerboost—an extra power mode for those moments when you need (or simply want) maximum brightness. A simple flick of the high beam lever activates this impressive brightness, allowing you to easily adjust the auxiliary light's output according to your needs. With the new generation of powerboost from Ledson, you can seamlessly switch modes using the high beam flash in just a few easy steps, as shown here. Note: Your auxiliary light is delivered in E-approved mode. Please follow the instructions to activate powerboost mode.

What more is needed?

• Connection: Ledson Connect 6-pin cable harness, connect your auxiliary lights with a few clicks!
  With Connect, installation is simple - the cable harness with ready-made connectors fits all cars with halogen, xenon or LED high beams.
  Plug & Play: Avoid complicated installations - connect directly with the included wire tap connector or adapter cable (accessory), no damage to the car's original wiring.
  Smart functionality: Control both auxiliary lights and position lights directly via the wiring.
  Flexible: Add switch harness (7801009) to be able to turn off the auxiliary lights in fog or snow.
  Compatible with XBB: Perfect solution for cars with Xenon or LED - no damage to the original wiring with XBB Dongle and Power Unit.
• Mounting on the vehicle: Can be mounted directly on the vehicle (drill in a suitable place) or a little smoother and more stylish using a number plate holder

Specifications:

• Strobe light with five different patterns (one R65-approved)
• Range E-approved mode: 360 m (1 lux)

• Range powerboost mode: 747 m (1 lux)

• With position light, yellow-orange or xenon white (connect the colour you want)
• Driving Beam light pattern (enhances the vehicle's regular high beam pattern)
• E-marked ECE R112 (Ref. 30), R65, R10 / R7 (white position light) - Read more about UNECE regulations here
• EMC-protected (does not interfere with radio)

• Powerboost mode: 16,500 lumens (theoretical), 11,500 lumens (actual)

• Neutral white light (5000K)
• Combines TIR (Total Inner Reflection) with side-reflective optics to achieve the most even light distribution possible without disturbing spill light
• ETM (Electronic Thermal Management) - adjusts the strength of the diodes depending on how hot they are for optimal lifespan
• Pressure equalization membrane
• Aluminum housing
• Adjustable stainless steel bracket
• Polycarbonate lens
• Supplied individually

Technical data:

• 160W (4 x 30W LED + 4 x 10W LP LED)
• IP68/IP69K (water and dust proof)
• DT connector 6 pin supplied
• Voltage 9-36 V
• E-marked: 2,2A @ 12V and 1,1A @ 24V
• Powerboost: 13A @ 12V and 5,8A @ 24V

Dimensions & weight:

• Width: 218 mm
• Height: 218 mm (232 mm incl bracket)
• Depth: 84 mm
• Weight: 1,8 kg

Supplied:

• Ledson Sarox9+ Gen2 Strobe LED light 9"
• Bracket, bolts and screws for attaching the auxiliary light with either one or two attachment points
• DT connector (6-pole) that works with Ledson Connect
• Installation instructions
• DT adapter

Installation instructions for cables (detailed instructions included with the product):

• Red: Auxiliary light (+)
• Black: Auxiliary light / Position light (- ground)
• White: Position light (+) white light
• Yellow: Position light (+) yellow-orange light
• Green: Strobe light (+)
• Blue: Synchronization and strobe patterns

NOTE: The DT connector must not be cut, as this increases the risk of moisture damage and the warranty will cease to apply.
