LEDSON Sarox9+ Gen2 LED Spot Light

Sarox9+ Gen2 Strobe has 11,500 effective lumens and a solid 747-meter range in powerboost mode (360 meters in E-approved mode), providing a balanced combination of width and range.

Combo beam pattern
The light has a combined light pattern, meaning that it both scatters light in a wide area close to the vehicle, but also focuses light far away. This beam pattern is ideal if you want a lot of light near the vehicle for the smaller roads but still have the length to light up the road far ahead.

Pulse-Controlled powerboost - It doesn't get smoother than this
Sarox9+ Gen2 Strobe comes equipped with powerboost—an extra power mode for those moments when you need (or simply want) maximum brightness. A simple flick of the high beam lever activates this impressive brightness, allowing you to easily adjust the auxiliary light's output according to your needs. With the new generation of powerboost from Ledson, you can seamlessly switch modes using the high beam flash in just a few easy steps, as shown here. Note: Your auxiliary light is delivered in E-approved mode. Please follow the instructions to activate powerboost mode.

What more is needed?

• Connection: Ledson Connect 4-pin cable harness, connect your auxiliary lights with a few clicks!
  With Connect, installation is simple - the cable harness with ready-made connectors fits all cars with halogen, xenon or LED high beams.
  Plug & Play: Avoid complicated installations - connect directly with the included wire tap connector or adapter cable (accessory), no damage to the car's original wiring.
  Smart functionality: Control both auxiliary lights and position lights directly via the wiring.
  Flexible: Add switch harness (7801009) to be able to turn off the auxiliary lights in fog or snow.
  Compatible with XBB: Perfect solution for cars with Xenon or LED - no damage to the original wiring with XBB Dongle and Power Unit.
• Mounting on the vehicle: Can be mounted directly on the vehicle (drill in a suitable place) or a little smoother and more stylish using a number plate holder

Stone chip protection and snow filter
For vehicles where the auxiliary lights are exposed to harsh conditions, we recommend adding stone chip protection to minimise the risk of stone chips and scratches and thus extend the service life. Snow filters are also available as Accessories. See related products.

Specifications:

• With position light, yellow-orange or xenon white (connect the color you want)
• Combo beam pattern
• E-marked ECE R112 (Ref. 30), R10 / R7 (white position light) - Read more about UNECE regulations here
• Range E-approved mode: 360 m (1 lux)

• Range powerboost mode: 747 m (1 lux)

• EMC secured
• Powerboost mode: 16,500 lumens (theoretical), 11,500 lumens (actual)
• Neutral white light (5000K)
• TIR (Total Inner Reflection)
• ETM (Electronic Thermal Management)
• Side reflective optical system
• Pressure equalization membrane
• Aluminum heatsink
• Adjustable bracket in stainless steel
• Lexan polycarbonate front cover
• Polycarbonate Lens
• 36 month warranty

Technical data:

• 160W (4 x 30W LED + 4 x 10W LP LED)
• IP68/IP69K (water and dust proof)
• DT connector 4 pin supplied
• Voltage 9-36 V
• E-marked: 2,2A @ 12V and 1,1A @ 24V
• Powerboost: 13A @ 12V and 5,8A @ 24V

Dimensions & weight:

• Width: 218 mm
• Height: 218 mm (233 mm incl bracket)
• Depth: 84 mm
• Cable length: 42 cm
• Weight: 1,8 kg

Supplied:

• Ledson Sarox9+ LED light 9"
• Bracket, bolts and screws for attaching the auxiliary light with either one or two attachment points
• DT connector (4-pole)
• Installation instructions
• DT adapter

Installation instructions for cables (detailed instructions included with the product):

• Red: Auxiliary light (+)
• Black: Auxiliary light / Position light (- ground)
• White: Position light (+) white light
• Yellow: Position light (+) yellow-orange light

NOTE: The DT connector must not be cut, as this increases the risk of moisture damage and the warranty will cease to apply.
